"Track-Jet" Hydrodemolition Machine

TRACK JET is a cutting-edge machine designed and built by Laurini Officine Meccaniche for hydrodemolition and surface removal inside tunnels. Engineered to perform with precision, reliability, and safety, TRACK JET represents a new benchmark in the field of automated tunnel restoration.

Specifically developed to remove the superficial concrete layers of tunnel linings, TRACK JET employs one or more high-pressure water jet nozzles mounted on a telescopic boom capable of covering a working arc of 220°. Its fully remote-controlled operation allows a single operator to manage all functions safely from the ground, ensuring maximum control and visibility while minimizing exposure to debris and noise.

Thanks to its electric drive system and hydraulic transmission, TRACK JET operates efficiently and silently within enclosed environments, maintaining excellent maneuverability even in confined tunnel sections. The hydraulically operated tracks provide exceptional traction and stability, allowing the machine to operate on variable surfaces and gradients.

Equipped with a robust structural frame and precision-engineered components, TRACK JET combines power with technological sophistication. It includes high-performance electric motors, a Danfoss hydraulic system, and a Scanreco remote-control unit, ensuring reliability and user-friendly operation. The system’s modular configuration allows for rapid setup, easy maintenance, and consistent performance in demanding underground conditions.

Technical Features

• Machine Type: Hydrodemolition unit for tunnel vaults
• Operating Weight: 19,000 kg
• Power Supply: Electric (24 V system)

Electric Drive Motors:

• Movement: 1 × ECHTOP MOTOR T3CR 225 S-4
• Translation: 2 × C.F.R. Encoder 80 pulses RT
• Hydraulic System: High-efficiency with max pressure of 300 bar
• Hydraulic Oil Tank Capacity: 350 liters
• Track Width: 700 mm
• Remote Control System: Scanreco S0008
• Working Arc: 220° tunnel coverage via telescopic arm
• Operational Slope Limits: Within manufacturer’s specified gradients

Environmental Limits:

• Temperature: –20°C to +40°C
• Altitude: up to 2000 m
• Relative Humidity: 80% max

Performance and Innovation

TRACK JET delivers outstanding performance in hydrodemolition, offering superior precision, minimal vibration, and environmentally safe operation without dust or chemical contaminants. The telescopic boom and adjustable nozzles allow targeted removal of deteriorated concrete while preserving structural integrity.

Designed for tunnel maintenance, concrete restoration, and structural rehabilitation, TRACK JET ensures clean, controlled, and consistent material removal with minimal operator intervention. Its electric power system makes it particularly suitable for use in enclosed or urban tunnel environments where emission reduction and low noise levels are essential.

With its combination of technological excellence, Italian engineering, and focus on operator safety, Laurini TRACK JET stands as the ultimate solution for modern tunnel hydrodemolition powerful, precise, and purpose-built for the future of infrastructure renewal.
